Birmingham Canal Navigations (Main Line)

The Birmingham Canal Navigations (Main Line) is a narrow canal and is part of the Birmingham Canal Navigations. It runs for 16 miles and ¾ furlongs through 24 locks from Worcester Bar (where it joins the Worcester and Birmingham Canal (Birmingham to King's Norton)) to Aldersley Junction (where it joins the Staffordshire and Worcestershire Canal (Main Line: Stourton to Aldersley) and the Staffordshire and Worcestershire Canal (Main Line: Aldersley to Autherley)).

The maximum dimensions for a boat to be able to travel on the waterway are 72 feet long and 7 feet wide. The maximum headroom is not known. The maximum draught is not known.

Notable features of the waterway include: Galton Tunnel, Factory Locks, Coseley Tunnel, Wolverhampton Tunnel and Wolverhampton Locks

Worcester Bar Junction of Worcester and Birmingham Canal with BCN
Worcester Bar Footbridge	a few yards	0 locks
Gas Street Basin (Old Wharf)	¼ furlongs	0 locks
Broad Street 'Tunnel'	¾ furlongs	0 locks
Symphony Hall Footbridge	1¼ furlongs	0 locks
Brewmasters Bridge	1¾ furlongs	0 locks
Deep Cuttings Junction Often erroneously called Farmer's Bridge Junction. Junction of BCN Main Line and Newhall Branch. The Island is a vent for the Birmingham - Wolverhanpton Railway line	2½ furlongs	0 locks
Deep Cuttings Bridge	4¼ furlongs	0 locks
Old Turn Junction	4¾ furlongs	0 locks
Cast Iron Roving Bridge	5 furlongs	0 locks
Sheepcote Street Bridge	6¼ furlongs	0 locks
Ladywood Junction Western end of Oozells Street Loop	7 furlongs	0 locks
St. Vincent Street Bridge	7¼ furlongs	0 locks
Monument Lane Basin	1 mile and 2 furlongs	0 locks
Monument Road Bridge	1 mile and 2½ furlongs	0 locks
Sandy Turn Eastern end of Icknield Port Road Wharf Loop (Don't think there's a tow-path around the loop)	1 mile and 3¾ furlongs	0 locks
Rotton Park Junction Western end of Icknield Port Road Wharf Loop and eastern end of Soho Loop	1 mile and 4¾ furlongs	0 locks
Rotton Park Towpath Bridge	1 mile and 5 furlongs	0 locks
Site of Harborne Branch Railway Bridge	1 mile and 5¾ furlongs	0 locks
Lee Bridge	1 mile and 7 furlongs	0 locks
Winson Green Bridge	2 miles and 1 furlong	0 locks
Winson Green Junction Western end of Soho Loop	2 miles and 3 furlongs	0 locks
Winson Green Roving Bridge	2 miles and 3½ furlongs	0 locks
Winson Green Gauging Island None of the original building survive	2 miles and 3½ furlongs	0 locks
Cape Arm Junction (closed)	2 miles and 5½ furlongs	0 locks
Soho Railway Bridge Line to Smethwick Station	2 miles and 7 furlongs	0 locks
French Walls Basin Bridge	3 miles and 1 furlong	0 locks
Rabone Lane Bridge	3 miles and 1¼ furlongs	0 locks
Smethwick Main Line Turnover Bridge	3 miles and 3 furlongs	0 locks
Smethwick Junction Junction of BCN Old and New Main Lines	3 miles and 3 furlongs	0 locks
Rolfe Bridge	3 miles and 4¼ furlongs	0 locks
Rolfe Pipe Bridge	3 miles and 4¼ furlongs	0 locks
Smethwick Stop Only the island remains	3 miles and 5½ furlongs	0 locks
Engine Arm Aqueduct Overhead Telford Aqueduct	3 miles and 6 furlongs	0 locks
Brass House Bridge	4 miles	0 locks
Pump House	4 miles and ¼ furlongs	0 locks
Galton Tunnel (Southeast end) Telford Way (A4168) crosses the tunnel	4 miles and 2½ furlongs	0 locks
Galton Tunnel (Northwest end)	4 miles and 3 furlongs	0 locks
Galton Bridge	4 miles and 3¼ furlongs	0 locks
Smethwick Railway Bridge Smethwick West Station is immediately southwest from here	4 miles and 3½ furlongs	0 locks
Spon Lane Station Bridge	4 miles and 7¾ furlongs	0 locks
Chances Bridge	5 miles and ¾ furlongs	0 locks
Hartley Bridge (Bromford)	5 miles and 1 furlong	0 locks
Steward Aqueduct Overhead Carries the Old Main line over the New Main line	5 miles and 1¾ furlongs	0 locks
M5 Motorway Overhead	5 miles and 2 furlongs	0 locks
Bromford Junction Roving Bridge	5 miles and 4¼ furlongs	0 locks
Bromford Junction Junction of Spon Lane Locks Branch with BCN Main Line	5 miles and 4¾ furlongs	0 locks
Bromford Stop Island	5 miles and 5 furlongs	0 locks
Lattice Accommodation Bridge	5 miles and 5¾ furlongs	0 locks
Bromford Bridge	5 miles and 7¼ furlongs	0 locks
Izon Old Turn Eastern End	6 miles and 1 furlong	0 locks
Pudding Green Junction Junction of Wednesbury Old Canal with BCN Main Line	6 miles and 3 furlongs	0 locks
Albion Bridge	6 miles and 3½ furlongs	0 locks
Albion Railway Bridge Railway between Sandwell and Dudley and Dudley Port stations	6 miles and 5¼ furlongs	0 locks
Union Furnace Bridge	6 miles and 5½ furlongs	0 locks
Albion Junction Junction of Gower Branch with BCN Main Line	6 miles and 7 furlongs	0 locks
Dunkirk Stop Island	6 miles and 7½ furlongs	0 locks
Moors Aqueduct Not really an aqueduct as the stream is piped under the embankment.	7 miles and 1 furlong	0 locks
Site of Rattlechain Brickworks Basin No access to the basin	7 miles and 2 furlongs	0 locks
Coopers Aqueduct Crosses a footpath tunnel	7 miles and 4 furlongs	0 locks
Dudley Port Junction Bridge	7 miles and 4½ furlongs	0 locks
Dudley Port Junction Junction of Netherton Tunnel Branch with BCN Main Line	7 miles and 4¾ furlongs	0 locks
Rattlechain Bridge Towpath bridge over Dixon's Basin	7 miles and 5¼ furlongs	0 locks
Ryland Aqueduct	7 miles and 6¾ furlongs	0 locks
Dudley Port Station Aqueduct	7 miles and 7½ furlongs	0 locks
Puppy Green Aqueduct	8 miles	0 locks
Puppy Green Pipe Bridge	8 miles and ¼ furlongs	0 locks
Watery Lane Bridge	8 miles and 3¾ furlongs	0 locks
Watery Lane Pipe Bridge	8 miles and 3¾ furlongs	0 locks
Caggy's Yard Bridge	8 miles and 4½ furlongs	0 locks
Watery Lane Junction Junction with closed Tipton Green and Toll End Communication	8 miles and 4½ furlongs	0 locks
Caggy's Yard	8 miles and 4¾ furlongs	0 locks
Tipton Station Bridge	8 miles and 5½ furlongs	0 locks
Tipton Station Arm (closed)	8 miles and 5¾ furlongs	0 locks
Tipton Station Pipe Bridge	8 miles and 5¾ furlongs	0 locks
Wood Street Footbridge	8 miles and 6¾ furlongs	0 locks
Factory Footbridge	8 miles and 7¼ furlongs	0 locks
Factory Bottom Lock	8 miles and 7½ furlongs	0 locks
Factory Lock No 2	8 miles and 7¾ furlongs	1 lock
Factory Road Bridge	9 miles	2 locks
Factory Top Lock No 1 A "Water Conservation Key" is needed for these locks. These are available from BW offices and from boatyards	9 miles and ¼ furlongs	2 locks
Factory Junction Bridge	9 miles and ½ furlongs	3 locks
Tipton Factory Junction Junction of BCN Old and New Main Lines. Access to the Barge & Barrel PH	9 miles and ¾ furlongs	3 locks
Factory Bridge	9 miles and ¾ furlongs	3 locks
Factory Bridge Arm (closed)	9 miles and 1 furlong	3 locks
Bloomfield Pipe Bridge	9 miles and 2½ furlongs	3 locks
Bloomfield Junction Former junction with southern end of Wednesbury Oak Loop; Ox Leasowes Foot Bridge to Bean Road Industrial Estate	9 miles and 3¼ furlongs	3 locks
Wallbrook Bridge	9 miles and 5¼ furlongs	3 locks
Footbridge to Old End Lane Pipe Bridge is next to footbridge	9 miles and 5½ furlongs	3 locks
Coseley Tunnel (South end)	9 miles and 7 furlongs	3 locks
Coseley Tunnel (North end)	10 miles and ½ furlongs	3 locks
Coseley School Footbridge	10 miles and 1 furlong	3 locks
Deepfields Foot Bridge	10 miles and 2¼ furlongs	3 locks
Deepfields Pipe Bridge	10 miles and 2¼ furlongs	3 locks
Hills Bridge	10 miles and 4 furlongs	3 locks
Hills Bridge Winding Hole	10 miles and 4½ furlongs	3 locks
Anchor Bridge (Deepfields)	10 miles and 5¼ furlongs	3 locks
Deepfields Junction Junction of Wednesbury Oak Loop Line with BCN Main Line	10 miles and 5½ furlongs	3 locks
Black Country Route Bridge	10 miles and 6¼ furlongs	3 locks
Ladymore Basin Narrows	11 miles and ½ furlongs	3 locks
Turton Croft Bridge	11 miles and 1 furlong	3 locks
Ettingshall Arm Junction	11 miles and 3¼ furlongs	3 locks
Parkfield Railway Bridge Birmingham to Wolverhampton Main Line	11 miles and 3¼ furlongs	3 locks
Millfields Bridge	11 miles and 6 furlongs	3 locks
Gibbet Lane Bridge	11 miles and 7 furlongs	3 locks
Catchems Corner Bridge Pipe bridges both sides	12 miles and 1¾ furlongs	3 locks
Rough Hills Gauging Station	12 miles and 4¼ furlongs	3 locks
Rough Hills Railway Bridge Birmingham to Wolverhampton Main Line	12 miles and 4½ furlongs	3 locks
Rough Hills Lane Bridge	12 miles and 6 furlongs	3 locks
Monmore Green Bridge	12 miles and 7½ furlongs	3 locks
Bilston Street Bridge	13 miles and 2 furlongs	3 locks
Chillington Interchange Basin No access to basin	13 miles and 2¼ furlongs	3 locks
Chillington Electricty Cables Bridge	13 miles and 3 furlongs	3 locks
Walsall Street Winding Hole Old Grand Junction Wharf entrance	13 miles and 3¾ furlongs	3 locks
Walsall Street Bridge	13 miles and 4½ furlongs	3 locks
Minerva Wharf Arm Entrance to the old Minerva Wharf	13 miles and 4¾ furlongs	3 locks
Pickford's Wharf	13 miles and 4¾ furlongs	3 locks
Corporation Wharf Arm Entrance to the old Corporation Wharf	13 miles and 5 furlongs	3 locks
Horseley Fields Bridge	13 miles and 5¼ furlongs	3 locks
Horseley Fields Junction Junction of the BCN (Main Line) with the Wyrley and Essington Canal	13 miles and 5½ furlongs	3 locks
Albion Wharf	13 miles and 7½ furlongs	3 locks
Mill Street Bridge	14 miles and ¼ furlongs	3 locks
Wolverhampton Tunnel (Southeast end) Corn Street crosses here	14 miles and ½ furlongs	3 locks
Wolverhampton Tunnel (Northwest end) Railway Drive crosses here	14 miles and 1 furlong	3 locks
Broad Street Basin BW yard with facilities	14 miles and 1¾ furlongs	3 locks
Broad Street Bridge	14 miles and 2 furlongs	3 locks
Wolverhampton Moorings for town	14 miles and 2¼ furlongs	3 locks
Wolverhampton Top Lock No 1	14 miles and 3½ furlongs	3 locks
Little's Lane Bridge	14 miles and 5¼ furlongs	4 locks
Wolverhampton Lock No 2	14 miles and 5½ furlongs	4 locks
Wolverhampton Lock No 3	14 miles and 6¼ furlongs	5 locks
Wolverhampton Railway Bridge Wolverhampton High Level Station to the North and West	14 miles and 6½ furlongs	6 locks
Wolverhampton Lock No 4	14 miles and 6½ furlongs	6 locks
Wolverhampton Lock No 5	14 miles and 7 furlongs	7 locks
Cannock Road Bridge	14 miles and 7¼ furlongs	8 locks
Wolverhampton Lock No 6	14 miles and 7½ furlongs	8 locks
Wolverhampton Lock No 7	15 miles	9 locks
Wolverhampton Lock No 8	15 miles and ½ furlongs	10 locks
Jordan Bridge	15 miles and ½ furlongs	11 locks
Wolverhampton Lock No 9	15 miles and 1 furlong	11 locks
Wolverhampton Lock No 10	15 miles and 1¼ furlongs	12 locks
Foxs Lane Bridge	15 miles and 1½ furlongs	13 locks
Wolverhampton Lock No 11	15 miles and 1¾ furlongs	13 locks
Railway Bridge - Bilbrook to the North With a disused railway bridge alongside	15 miles and 2 furlongs	14 locks
Stour Valley Viaduct Railway Line Wolverhampton to the North	15 miles and 2 furlongs	14 locks
Wolverhampton Lock No 12	15 miles and 2¼ furlongs	14 locks
Gorsebrook Pipe Bridge	15 miles and 2½ furlongs	15 locks
Wolverhampton Lock No 13	15 miles and 2¾ furlongs	15 locks
Wolverhampton Lock No 14	15 miles and 3¼ furlongs	16 locks
Wolverhampton Lock No 15	15 miles and 3¾ furlongs	17 locks
Gorsebrook Bridge Also called Stafford Bridge	15 miles and 3¾ furlongs	18 locks
Wolverhampton Lock No 16	15 miles and 4¼ furlongs	18 locks
Spring Bridge Carries the Wolverhampton Railway to the West	15 miles and 4¾ furlongs	19 locks
Wolverhampton Lock No 17	15 miles and 5½ furlongs	19 locks
Wolverhampton Lock No 18	15 miles and 6½ furlongs	20 locks
Wolverhampton Lock No 19	15 miles and 7½ furlongs	21 locks
Dunstall Park Bridge	15 miles and 7½ furlongs	22 locks
Wolverhampton Lock No 20	16 miles	22 locks
Wolverhampton Bottom Lock No 21	16 miles and ½ furlongs	23 locks
Aldersley Junction Bridge	16 miles and ½ furlongs	24 locks
Aldersley Junction Junction of the Staffordshire and Worcestershire Canal Main Line with the Birmingham Canal Navigations Main Line	16 miles and ¾ furlongs	24 locks
