Middle Level Navigations (Forty Foot River)



The Middle Level Navigations (Forty Foot River) is a broad canal and is part of the Middle Level Navigations. It runs for through 2 locks from Forty Foot River - Old Bedford River Junction (where it joins the River Great Ouse (Counter Wash Drain) and the River Great Ouse (Old Bedford River)) to Old River Nene - Forty Foot River Junction (where it joins the Middle Level Navigations (Old River Nene)).

The maximum dimensions for a boat to be able to travel on the waterway are 72 feet long and 13 feet wide. The maximum headroom is not known. The maximum draught is not known.

It has a junction with the Middle Level Navigations (Sixteen Foot River) at Sixteen Foot Corner.



Forty Foot River - Old Bedford River Junction
Junction of Forty Foot River with the Old Bedford River
Welches Dam Sluice a few yards 0 locks
Horseway Sluice 1 mile and 3¾ furlongs 1 lock
Horseway Village Bridge 1 mile and 7¼ furlongs 2 locks
Sixteen Foot Corner
Junction of Forty Foot and Sixteen Foot Rivers
2 miles and 1½ furlongs 2 locks
Chatteris Road Bridge
With Pipe Bridge alongside
3 miles and 7¾ furlongs 2 locks
Leonard Child's Bridge 4 miles and 5¾ furlongs 2 locks
Puddock Bridge 6 miles and 6¼ furlongs 2 locks
Ramsey Hollow Bridge 7 miles and 6¼ furlongs 2 locks
Forty Foot Bridge 9 miles and 4 furlongs 2 locks
Old River Nene - Forty Foot River Junction
Junction of Old River Nene and Forty Foot River
10 miles 2 locks
